‧AC‧IGE12025
|
|
|
|
Rated
Volt | Voltage
Range | Freq | Input
Power | Ref.
Speed | Max.Airflow | Max.Static Pressure | Noise
Level | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | IGE12025_1M | 115 | 50/60 | 14/13 | 2000/2200 | 58.2/73.6 | 1.65/2.09 | 0.16/0.19 | 4.1/4.9 | 34/35 | IGE12025_2M | 230 | 50/60 | 14/13 | 2000/2200 | 58.2/73.6 | 1.65/2.09 | 0.16/0.19 | 4.1/4.9 | 34/35 | IGE12025_1H | 115 | 50/60 | 14/13 | 2200/2500 | 64.0/81.0 | 1.81/2.29 | 0.20/0.23 | 5.0/5.9 | 37/38 | IGE12025_2H | 230 | 50/60 | 14/13 | 2200/2500 | 64.0/81.0 | 1.81/2.29 | 0.20/0.23 | 5.0/5.9 | 37/38 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
| |
 |
| Motor type： | Shade Pole AC Motor | |
| IP Protection： | - | |  |
| Frame： | Aluminum die cast, black color | |
| Impeller： | Plastic(94V-0) | |
| Bearing： | Ball ; Sleeve bearings | |
| Weights： | 0.37 KG |
|
|
|
 |
|
 |
|
|
