‧AC‧IGE17238
|
|
|
|
Rated
Volt | Voltage
Range | Freq | Input
Power | Ref.
Speed | Max.Airflow | Max.Static Pressure | Noise
Level | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | IGE17238_1M(SHADE) | 115 | 50/60 | 39/35 | 2400/2600 | 161.0/170.0 | 4.56/4.81 | 0.37/0.39 | 9.5/10.0 | 50/51 | IGE17238_2M(SHADE) | 230 | 50/60 | 39/35 | 2400/2600 | 161.0/170.0 | 4.56/4.81 | 0.37/0.39 | 9.5/10.0 | 50/51 | IGE17238_1H(CAP) | 115 | 50/60 | 27/29 | 2800/3200 | 189.0/220.0 | 5.35/6.23 | 0.57/0.59 | 14.4/15.1 | 54/58 | IGE17238_2H(CAP) | 230 | 50/60 | 27/29 | 2800/3200 | 189.0/220.0 | 5.35/6.23 | 0.57/0.59 | 14.4/15.1 | 54/58 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
| |
|
|
 |
|
 |
|
|
