‧AC‧IGE25489
|
|
|
|
| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | | Model No | VAC | Hz | Watt | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | | IGE25489_1M | 115 | 50/60 | 34/37 | 1400/1600 | 450.0/520.0 | 12.74/14.72 | 0.26/0.31 | 6.6/7.9 | 49/51 | | IGE25489_2M | 230 | 50/60 | 34/37 | 1400/1600 | 450.0/520.0 | 12.74/14.72 | 0.26/0.31 | 6.6/7.9 | 49/51 | | IGE25489_1H | 115 | 50/60 | 60/67 | 2000/2150 | 630.0/700.0 | 17.84/19.82 | 0.31/0.34 | 7.9/8.7 | 54/56 | | IGE25489_1H | 230 | 50/60 | 60/67 | 2000/2150 | 630.0/700.0 | 17.84/19.82 | 0.31/0.34 | 7.9/8.7 | 54/56 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
| |
|
|
 |
|
 |
|
|
