| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE02510_05L | 5.0 | 4.5/5.5 | 0.08 | 7000 | 1.32 | 0.04 | 0.07 | 1.85 | 20.0 | AGE02510_12L | 12.0 | 7.0/13.2 | 0.07 | 7000 | 1.32 | 0.04 | 0.07 | 1.85 | 20.0 | AGE02510_05M | 5.0 | 4.5/5.5 | 0.13 | 10000 | 1.85 | 0.05 | 0.17 | 4.36 | 23.5 | AGE02510_12M | 12.0 | 7.0/13.2 | 0.10 | 10000 | 1.85 | 0.05 | 0.17 | 4.36 | 23.5 | AGE02510_24M | 24.0 | 14.0/26,2 | 0.04 | 10000 | 1.85 | 0.05 | 0.17 | 4.36 | 23.5 | AGE02510_05H | 5.0 | 4.5/5.5 | 0.20 | 11000 | 2.04 | 0.06 | 0.21 | 5.28 | 25.6 | AGE02510_12H | 12.0 | 7.0/13.2 | 0.08 | 11000 | 2.04 | 0.06 | 0.21 | 5.28 | 25.6 | AGE02510_24H | 24.0 | 14.0/26,2 | 0.05 | 11000 | 2.04 | 0.06 | 0.21 | 5.28 | 25.6 | AGE02510_05U | 5.0 | 4.5/5.5 | 0.22 | 13000 | 2.41 | 0.07 | 0.29 | 7.31 | 28.0 | AGE02510_12U | 12.0 | 7.0/13.2 | 0.12 | 13000 | 2.41 | 0.07 | 0.29 | 7.31 | 28.0 | AGE02510_24U | 24.0 | 14.0/26,2 | 0.06 | 13000 | 2.41 | 0.07 | 0.29 | 7.31 | 28.0 |
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
