| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGQ03010_05M | 5.0 | 4.5/5.5 | 0.09 | 7500 | 3.54 | 0.10 | 0.13 | 3.36 | 20.0 | AGQ03010_12M | 12.0 | 7.0/13.2 | 0.05 | 7500 | 3.54 | 0.10 | 0.13 | 3.36 | 20.0 | AGQ03010_05H | 5.0 | 4.5/5.5 | 0.16 | 9000 | 4.26 | 0.12 | 0.19 | 4.83 | 23.3 | AGQ03010_12H | 12.0 | 7.0/13.2 | 0.07 | 9000 | 4.26 | 0.12 | 0.19 | 4.83 | 23.3 | AGQ03010_05U | 5.0 | 4.5/5.5 | 0.18 | 11000 | 5.37 | 0.15 | 0.22 | 5.66 | 27.4 | AGQ03010_12U | 7.0/13.2 | 7.0/13.2 | 0.09 | 11000 | 5.37 | 0.15 | 0.22 | 5.66 | 27.4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
