| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGB03828_12L | 12.0 | 7.0/13.2 | 0.11 | 8000 | 9.44 | 0.27 | 0.39 | 10.02 | 38.0 | AGB03828_12M | 12.0 | 7.0/13.2 | 0.15 | 10000 | 12.46 | 0.35 | 0.63 | 15.88 | 44.0 | AGB03828_12H | 12.0 | 7.0/13.2 | 0.29 | 13000 | 16.30 | 0.46 | 1.02 | 25.91 | 51.0 | AGB03828_12U | 12.0 | 7.0/13.2 | 0.43 | 15000 | 19.16 | 0.54 | 1.37 | 34.71 | 55.0 | AGB03828_12V | 12.0 | 7.0/13.2 | 0.58 | 17000 | 20.80 | 0.77 | 1.67 | 42.4 | 59.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
