| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGQ04020_24L | 24 | 14.0~26.2 | 0.07 | 5000 | 7.33 | 0.21 | 0.19 | 4.78 | 20.9 | AGQ04020_05M | 5 | 4.5~5.5 | 0.07 | 6500 | 9.50 | 0.27 | 0.32 | 8.05 | 24.9 | AGQ04020_12M | 12 | 7.0~13.2 | 0.12 | 6500 | 9.50 | 0.27 | 0.32 | 8.05 | 24.9 | AGQ04020_24M | 24 | 14.0~26.2 | 0.09 | 6500 | 9.50 | 0.27 | 0.32 | 8.05 | 24.9 | AGQ04020_12H | 12 | 7.0~13.2 | 0.16 | 8600 | 10.99 | 0.31 | 0.43 | 10.82 | 32.9 | AGQ04020_24H | 24 | 14.0~26.2 | 0.08 | 8600 | 10.99 | 0.31 | 0.43 | 10.82 | 32.9 | AGQ04020_12U | 12 | 7.0~13.2 | 0.10 | 10000 | 14.16 | 0.40 | 0.46 | 11.55 | 37.0 | AGQ04020_24L | 24 | 14.0~26.2 | 0.07 | 5000 | 7.33 | 0.21 | 0.19 | 4.78 | 20.9 | AGQ04020_05M | 5 | 4.5~5.5 | 0.07 | 6500 | 9.50 | 0.27 | 0.32 | 8.05 | 24.9 |
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
