| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGC04020_12H | 12 | 7.0~13.2 | 0.20 | 9000 | 11.00 | 0.31 | 0.39 | 9.90 | 36.7 | AGC04020_24H | 24 | 14.0~26.2 | 0.10 | 9000 | 11.00 | 0.31 | 0.39 | 9.90 | 36.7 | AGC04020_12U | 12 | 7.0~13.2 | 0.25 | 10500 | 12.80 | 0.36 | 0.50 | 12.70 | 40.2 | AGC04020_24U | 24 | 14.0~26.2 | 0.15 | 10500 | 12.80 | 0.36 | 0.50 | 12.70 | 40.2 | AGC04020_12V | 12 | 7.0~13.2 | 0.32 | 13000 | 15.90 | 0.45 | 0.80 | 20.30 | 46.2 | AGC04020_24V | 24 | 14.0~26.2 | 0.20 | 13000 | 15.90 | 0.45 | 0.80 | 20.30 | 46.2 | AGC04020_12H | 12 | 7.0~13.2 | 0.20 | 9000 | 11.00 | 0.31 | 0.39 | 9.90 | 36.7 | AGC04020_24H | 24 | 14.0~26.2 | 0.10 | 9000 | 11.00 | 0.31 | 0.39 | 9.90 | 36.7 | AGC04020_12U | 12 | 7.0~13.2 | 0.25 | 10500 | 12.80 | 0.36 | 0.50 | 12.70 | 40.2 |
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
