| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGB04028_12L | 12 | 7.0~13.2 | 0.17 | 8000 | 13.86 | 0.39 | 0.46 | 11.60 | 40.0 | AGB04028_24L | 24 | 14.0~26.2 | 0.16 | 8000 | 13.86 | 0.39 | 0.46 | 11.60 | 40.0 | AGB04028_12M | 12 | 7.0~13.2 | 0.20 | 9500 | 15.85 | 0.45 | 0.69 | 17.57 | 42.0 | AGB04028_24M | 24 | 14.0~26.2 | 0.10 | 9500 | 15.85 | 0.45 | 0.69 | 17.57 | 42.0 | AGB04028_12H | 12 | 7.0~13.2 | 0.36 | 11000 | 18.73 | 0.53 | 0.92 | 23.38 | 48.0 | AGB04028_24H | 24 | 14.0~26.2 | 0.16 | 11000 | 18.73 | 0.53 | 0.92 | 23.38 | 48.0 | AGB04028_12U | 12 | 7.0~13.2 | 0.51 | 13000 | 23.78 | 0.67 | 1.32 | 33.65 | 54.0 | AGB04028_24U | 24 | 14.0~26.2 | 0.23 | 13000 | 23.78 | 0.67 | 1.32 | 33.65 | 54.0 | AGB04028B48U | 48 | 28.0~56.0 | 0.81 | 13000 | 23.78 | 0.67 | 1.32 | 33.65 | 54 |
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
