| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGV04028_12H | 12 | 7.0~13.2 | 0.30 | 13000 | 15.20 | 0.43 | 0.92 | 23.37 | 46.7 | AGV04028_24H | 24 | 14.0~26.2 | 0.13 | 13000 | 15.20 | 0.43 | 0.92 | 23.37 | 46.7 | AGV04028_12U | 12 | 7.0~13.2 | 0.39 | 15000 | 17.80 | 0.50 | 1.20 | 30.48 | 49.8 | AGV04028_24U | 24 | 14.0~26.2 | 0.19 | 15000 | 17.80 | 0.50 | 1.20 | 30.48 | 49.8 | AGV04028_12V | 12 | 7.0~13.2 | 0.56 | 18000 | 22.92 | 0.65 | 1.91 | 48.62 | 53.8 | AGV04028_24V | 24 | 14.0~26.2 | 0.23 | 18000 | 22.92 | 0.65 | 1.91 | 48.62 | 53.8 | AGV04028_12H | 12 | 7.0~13.2 | 0.30 | 13000 | 15.20 | 0.43 | 0.92 | 23.37 | 46.7 | AGV04028_24H | 24 | 14.0~26.2 | 0.13 | 13000 | 15.20 | 0.43 | 0.92 | 23.37 | 46.7 | AGV04028_12U | 12 | 7.0~13.2 | 0.39 | 15000 | 17.80 | 0.50 | 1.20 | 30.48 | 49.8 |
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
