| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGY04028_12U | 12 | 7.0~13.2 | 0.06 | 23000 | 30.50 | 0.86 | 3.41 | 86.67 | 62.5 | AGY04028_12V | 12 | 7.0~13.2 | 0.06 | 25000 | 34.50 | 0.98 | 4.15 | 105.30 | 64.0 | AGY04028_12W | 12 | 7.0~13.2 | 2.10 | 30000 | 39.09 | 1.11 | 5.72 | 145.40 | 69.5 | AGY04028_12F | 12 | 7.0~13.2 | 3.80 | 38000 | 49.51 | 1.40 | 9.30 | 236.30 | 74.2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
