| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE05010_05J | 5 | 4.5~5.5 | 0.04 | 3500 | 6.71 | 0.19 | 0.05 | 1.35 | 18.0 | AGE05010_12J | 12 | 7.0~13.2 | 0.02 | 3500 | 6.71 | 0.19 | 0.05 | 1.35 | 18.0 | AGE05010_05L | 5 | 4.5~5.5 | 0.08 | 4500 | 8.63 | 0.24 | 0.09 | 2.24 | 25.0 | AGE05010_12L | 12 | 7.0~13.2 | 0.03 | 4500 | 8.63 | 0.24 | 0.09 | 2.24 | 25.0 | AGE05010_05M | 5 | 4.5~5.5 | 0.16 | 5500 | 10.54 | 0.30 | 0.14 | 3.50 | 30.0 | AGE05010_12M | 12 | 7.0~13.2 | 0.04 | 5500 | 10.54 | 0.30 | 0.14 | 3.50 | 30.0 | AGE05010_05H | 5 | 4.5~5.5 | 0.25 | 6500 | 12.70 | 0.36 | 0.18 | 4.45 | 35.0 | AGE05010_12H | 12 | 7.0~13.2 | 0.06 | 6500 | 12.70 | 0.36 | 0.18 | 4.45 | 35.0 |
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
