| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE05015_12J | 12 | 7.0~13.2 | #N/A | 3600 | 9.91 | 0.28 | 0.08 | 2.13 | 24.0 | AGE05015_24J | 24 | 14.0~26.2 | #N/A | 3600 | 9.91 | 0.28 | 0.08 | 2.13 | 24.0 | AGE05015_12L | 12 | 7.0~13.2 | #N/A | 4200 | 12.00 | 0.34 | 0.12 | 2.95 | 27.0 | AGE05015_24L | 24 | 14.0~26.2 | #N/A | 4200 | 12.00 | 0.34 | 0.12 | 2.95 | 27.0 | AGE05015_12M | 12 | 7.0~13.2 | #N/A | 4800 | 13.20 | 0.37 | 0.16 | 3.94 | 30.0 | AGE05015_24M | 24 | 14.0~26.2 | #N/A | 4800 | 13.20 | 0.37 | 0.16 | 3.94 | 30.0 | AGE05015_12H | 12 | 7.0~13.2 | 0.07 | 5400 | 15.00 | 0.42 | 0.18 | 4.67 | 32.0 | AGE05015_24H | 24 | 14.0~26.2 | #N/A | 5400 | 15.00 | 0.42 | 0.18 | 4.67 | 32.0 | AGE05015_12U | 12 | 7.0~13.2 | 0.08 | 6000 | 17.00 | 0.48 | 0.23 | 5.85 | 36.0 | AGE05015_24U | 24 | 14.0~26.2 | 0.05 | 6000 | 17.00 | 0.48 | 0.23 | 5.85 | 36.0 |
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
