| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE05020_12I | 12 | 7.0~13.2 | 0.10 | 4000 | 10.10 | 0.29 | 0.10 | 2.42 | 24.0 | AGE05020_24I | 24 | 14.0~26.2 | 0.07 | 4000 | 10.10 | 0.29 | 0.10 | 2.42 | 24.0 | AGE05020_12J | 12 | 7.0~13.2 | 0.13 | 4800 | 12.70 | 0.36 | 0.14 | 3.48 | 28.0 | AGE05020_24J | 24 | 14.0~26.2 | 0.08 | 4800 | 12.70 | 0.36 | 0.14 | 3.48 | 28.0 | AGE05020_12L | 12 | 7.0~13.2 | 0.15 | 5600 | 14.80 | 0.42 | 0.18 | 4.62 | 32.0 | AGE05020_24L | 24 | 14.0~26.2 | 0.06 | 5600 | 14.80 | 0.42 | 0.18 | 4.62 | 32.0 | AGE05020_12M | 12 | 7.0~13.2 | 0.21 | 6400 | 17.60 | 0.50 | 0.25 | 6.44 | 36.0 | AGE05020_24M | 24 | 14.0~26.2 | 0.12 | 6400 | 17.60 | 0.50 | 0.25 | 6.44 | 36.0 | AGE05020_12H | 12 | 7.0~13.2 | 0.19 | 7000 | 20.30 | 0.57 | 0.30 | 7.70 | 38.0 | AGE05020_24H | 24 | 14.0~26.2 | 0.08 | 7000 | 20.30 | 0.57 | 0.30 | 7.70 | 38.0 |
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
