| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE06020_12J | 12 | 7.0~13.2 | 0.07 | 3200 | 17.67 | 0.50 | 0.12 | 3.00 | 25.5 | AGE06020_24J | 24 | 14.0~26.2 | 0.03 | 3200 | 17.67 | 0.50 | 0.12 | 3.00 | 25.5 | AGE06020_12L | 12 | 7.0~13.2 | 0.09 | 3600 | 19.88 | 0.56 | 0.15 | 3.78 | 27.5 | AGE06020_24L | 24 | 14.0~26.2 | 0.04 | 3600 | 19.88 | 0.56 | 0.15 | 3.78 | 27.5 | AGE06020_12M | 12 | 7.0~13.2 | 0.11 | 4000 | 22.08 | 0.63 | 0.19 | 4.75 | 30.5 | AGE06020_24M | 24 | 14.0~26.2 | 0.08 | 4000 | 22.08 | 0.63 | 0.19 | 4.75 | 30.5 | AGE06020_12H | 12 | 7.0~13.2 | 0.13 | 4400 | 24.29 | 0.69 | 0.23 | 5.75 | 32.5 | AGE06020_24H | 24 | 14.0~26.2 | 0.10 | 4400 | 24.29 | 0.69 | 0.23 | 5.75 | 32.5 | AGE06020_12U | 12 | 7.0~13.2 | 0.17 | 4800 | 26.50 | 0.75 | 0.27 | 6.90 | 34.5 | AGE06020_24U | 24 | 14.0~26.2 | 0.12 | 4800 | 26.50 | 0.75 | 0.27 | 6.90 | 34.5 | AGE06020_12V | 12 | 7.0~13.2 | 0.25 | 6000 | 30.46 | 0.86 | 0.38 | 9.63 | 43.0 | AGE06020_24V | 24 | 14.0~26.2 | 0.13 | 6000 | 30.46 | 0.86 | 0.38 | 9.63 | 43.0 | AGE06020_12W | 12 | 7.0~13.2 | 0.35 | 7000 | 35.00 | 0.99 | 0.51 | 13.00 | 46.3 | AGE06020_24W | 24 | 14.0~26.2 | 0.16 | 7000 | 35.00 | 0.99 | 0.51 | 13.00 | 46.3 |
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
