| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE06015_12J | 12 | 7.0~13.2 | 0.08 | 3000 | 15.00 | 0.42 | 0.09 | 2.30 | 24.0 | AGE06015_12L | 12 | 7.0~13.2 | 0.05 | 3500 | 19.00 | 0.54 | 0.14 | 3.50 | 29.0 | AGE06015_12M | 12 | 7.0~13.2 | 0.09 | 4000 | 21.70 | 0.61 | 0.16 | 4.10 | 32.0 | AGE06015_24M | 24 | 14.0~26.2 | 0.10 | 4000 | 21.70 | 0.61 | 0.16 | 4.10 | 32.0 | AGE06015_12H | 12 | 7.0~13.2 | 0.07 | 4500 | 23.10 | 0.65 | 0.18 | 4.60 | 35.0 | AGE06015_24H | 24 | 14.0~26.2 | 0.07 | 4500 | 23.10 | 0.65 | 0.18 | 4.60 | 35.0 | AGE06015_12U | 12 | 7.0~13.2 | 0.16 | 5000 | 26.50 | 0.75 | 0.22 | 5.70 | 37.0 | AGE06015_24U | 24 | 14.0~26.2 | 0.14 | 5000 | 26.50 | 0.75 | 0.22 | 5.70 | 37.0 | AGE06015_12V | 12 | 7.0~13.2 | 0.18 | 5600 | 29.68 | 0.84 | 0.28 | 7.15 | 28.5 | AGE06015_24V | 24 | 14.0~26.2 | 0.80 | 5600 | 29.68 | 0.84 | 0.28 | 7.15 | 28.5 |
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
