| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE06025_12J | 12 | 7.0~13.2 | 0.05 | 3100 | 14.10 | 0.40 | 0.10 | 2.50 | 26.0 | AGE06025_24J | 24 | 14.0~26.2 | 0.07 | 3100 | 14.10 | 0.40 | 0.10 | 2.50 | 26.0 | AGE06025_48J | 48 | 28.0~56.0 | 0.05 | 3100 | 14.10 | 0.40 | 0.10 | 2.50 | 26.0 | AGE06025_12L | 12 | 7.0~13.2 | 0.12 | 3600 | 18.50 | 0.52 | 0.14 | 3.60 | 35.0 | AGE06025_24L | 24 | 14.0~26.2 | 0.08 | 3600 | 18.50 | 0.52 | 0.14 | 3.60 | 35.0 | AGE06025_48L | 48 | 28.0~56.0 | 0.11 | 3600 | 18.50 | 0.52 | 0.14 | 3.60 | 35.0 | AGE06025_12M | 12 | 7.0~13.2 | 0.16 | 4250 | 21.50 | 0.61 | 0.19 | 4.80 | 31.8 | AGE06025_24M | 24 | 14.0~26.2 | 0.11 | 4250 | 21.50 | 0.61 | 0.19 | 4.80 | 31.8 | AGE06025_48M | 48 | 28.0~56.0 | 0.07 | 4250 | 21.50 | 0.61 | 0.19 | 4.80 | 31.8 | AGE06025_12H | 12 | 7.0~13.2 | 0.25 | 5000 | 25.60 | 0.72 | 0.26 | 6.50 | 40.0 | AGE06025_24H | 24 | 14.0~26.2 | 0.07 | 5000 | 25.60 | 0.72 | 0.26 | 6.50 | 40.0 | AGE06025_48H | 48 | 28.0~56.0 | 0.07 | 5000 | 25.60 | 0.72 | 0.26 | 6.50 | 40.0 | AGE06025_12U | 12 | 7.0~13.2 | 0.19 | 5500 | 28.18 | 0.80 | 0.31 | 7.84 | 42.5 | AGE06025_24U | 24 | 14.0~26.2 | 0.15 | 5500 | 28.18 | 0.80 | 0.31 | 7.84 | 42.5 | AGE06025_12V | 12 | 7.0~13.2 | 0.40 | 7000 | 35.87 | 1.02 | 0.50 | 12.70 | 50.0 |
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
