| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGF06025_12J | 12 | 7.0~13.2 | 0.08 | 3100 | 19.97 | 0.57 | 0.12 | 2.95 | 26.0 | AGF06025_24J | 24 | 14.0~26.2 | 0.04 | 3100 | 19.97 | 0.57 | 0.12 | 2.95 | 26.0 | AGF06025_12L | 12 | 7.0~13.2 | 0.12 | 3600 | 23.19 | 0.66 | 0.16 | 3.98 | 31.0 | AGF06025_24L | 24 | 14.0~26.2 | 0.06 | 3600 | 23.19 | 0.66 | 0.16 | 3.98 | 31.0 | AGF06025_12M | 12 | 7.0~13.2 | 0.14 | 4250 | 27.38 | 0.78 | 0.22 | 5.55 | 34.0 | AGF06025_24M | 24 | 14.0~26.2 | 0.08 | 4250 | 27.38 | 0.78 | 0.22 | 5.55 | 34.0 | AGF06025_48M | 48 | 28.0~56.0 | 0.06 | 4250 | 27.38 | 0.78 | 0.22 | 5.55 | 34.0 | AGF06025_12H | 12 | 7.0~13.2 | 0.17 | 5000 | 32.21 | 0.91 | 0.30 | 7.68 | 40.0 | AGF06025_24H | 24 | 14.0~26.2 | 0.14 | 5000 | 32.21 | 0.91 | 0.30 | 7.68 | 40.0 | AGF06025_48H | 48 | 28.0~56.0 | 0.10 | 5000 | 32.21 | 0.91 | 0.30 | 7.68 | 40.0 | AGF06025_12U | 12 | 7.0~13.2 | 0.34 | 6800 | 43.80 | 1.24 | 0.56 | 14.20 | 56.0 | AGF06025_24U | 24 | 14.0~26.2 | 0.17 | 6800 | 43.80 | 1.24 | 0.56 | 14.20 | 56.0 | AGF06025_48U | 48 | 28.0~56.0 | 0.12 | 6800 | 43.80 | 1.24 | 0.56 | 14.20 | 56.0 | AGF06025_12V | 12 | 7.0~13.2 | 0.48 | 7500 | 47.90 | 1.36 | 0.79 | 20.00 | 62.5 | AGF06025_24V | 24 | 14.0~26.2 | 0.25 | 7500 | 47.90 | 1.36 | 0.79 | 20.00 | 62.5 | AGF06025_12W | 12 | 7.0~13.2 | 0.94 | 9800 | 55.50 | 1.57 | 1.17 | 29.72 | 66.0 |
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
