| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGB06038_12L | 12 | 7.0~13.2 | 0.52 | 8000 | 44.4 | 1.26 | 0.78 | 19.7 | 52.00 | AGB06038_24L | 24 | 14.0~26.2 | 0.32 | 8000 | 44.4 | 1.26 | 0.78 | 19.7 | 52.00 | AGB06038_48L | 48 | 28.0~56.0 | 0.18 | 8000 | 44.4 | 1.26 | 0.78 | 19.7 | 52.00 | AGB06038_12M | 12 | 7.0~13.2 | 0.71 | 9000 | 51.5 | 1.46 | 1.02 | 25.8 | 54.50 | AGB06038_24M | 24 | 14.0~26.2 | 0.36 | 9000 | 51.5 | 1.46 | 1.02 | 25.8 | 54.50 | AGB06038_48M | 48 | 28.0~56.0 | 0.20 | 9000 | 51.5 | 1.46 | 1.02 | 25.8 | 54.50 | AGB06038_12H | 12 | 7.0~13.2 | 1.00 | 10000 | 56.9 | 1.61 | 1.21 | 30.8 | 58.00 | AGB06038_24H | 24 | 14.0~26.2 | 0.47 | 10000 | 56.9 | 1.61 | 1.21 | 30.8 | 58.00 | AGB06038_48H | 48 | 28.0~56.0 | 0.34 | 10000 | 56.9 | 1.61 | 1.21 | 30.8 | 58.00 | AGB06038_12U | 12 | 7.0~13.2 | 1.38 | 12000 | 69.9 | 1.98 | 1.83 | 46.4 | 62.80 | AGB06038_24U | 24 | 14.0~26.2 | 0.71 | 12000 | 69.9 | 1.98 | 1.83 | 46.4 | 62.80 | AGB06038_48U | 48 | 28.0~56.0 | 0.35 | 12000 | 69.9 | 1.98 | 1.83 | 46.4 | 45.20 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
