| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE07015_12J | 12 | 7.0~13.2 | 0.11 | 2800 | 21.07 | 0.60 | 0.09 | 2.26 | 27.0 | AGE07015_12L | 12 | 7.0~13.2 | 0.13 | 3300 | 25.68 | 0.73 | 0.13 | 3.27 | 31.0 | AGE07015_12M | 12 | 7.0~13.2 | 0.13 | 3800 | 29.57 | 0.84 | 0.17 | 4.33 | 35.0 | AGE07015_12H | 12 | 7.0~13.2 | 0.25 | 4300 | 33.47 | 0.95 | 0.22 | 5.55 | 39.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
