| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGN08015_24J | 24 | 14.0~26.2 | 0.05 | 2400 | 23.37 | 0.66 | 0.09 | 2.29 | 26.0 | AGN08015_12L | 12 | 7.0~13.2 | 0.10 | 2700 | 29.34 | 0.83 | 0.11 | 2.79 | 29.0 | AGN08015_24L | 24 | 14.0~26.2 | 0.07 | 2700 | 29.34 | 0.83 | 0.11 | 2.79 | 29.0 | AGN08015_12M | 12 | 7.0~13.2 | 0.13 | 3100 | 33.50 | 0.95 | 0.13 | 3.39 | 32.0 | AGN08015_24M | 24 | 14.0~26.2 | 0.10 | 3100 | 33.50 | 0.95 | 0.13 | 3.39 | 32.0 | AGN08015_12H | 12 | 7.0~13.2 | 0.18 | 3600 | 40.12 | 1.14 | 0.18 | 4.57 | 37.0 | AGN08015_24H | 24 | 14.0~26.2 | 0.11 | 3600 | 40.12 | 1.14 | 0.18 | 4.57 | 37.0 | AGN08015_12U | 12 | 7.0~13.2 | 0.36 | 4500 | 47.16 | 1.34 | 0.26 | 6.60 | 41.0 | AGN08015_24U | 24 | 14.0~26.2 | 0.22 | 4500 | 47.16 | 1.34 | 0.26 | 6.60 | 41.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
