| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGN09225_12J | 12 | 7.0~13.2 | 0.09 | 2100 | 38.85 | 1.10 | 0.09 | 2.32 | 24.0 | AGN09225_12L | 12 | 7.0~13.2 | 0.11 | 2450 | 47.03 | 1.33 | 0.11 | 2.83 | 29.0 | AGN09225_12M | 12 | 7.0~13.2 | 0.14 | 2850 | 54.72 | 1.55 | 0.15 | 3.83 | 33.0 | AGN09225_12H | 12 | 7.0~13.2 | 0.20 | 3200 | 61.20 | 1.73 | 0.18 | 4.53 | 37.0 | AGN09225_24H | 24 | 14.0~26.2 | 0.15 | 3200 | 61.20 | 1.73 | 0.18 | 4.53 | 37.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
