| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGN12025_12J | 12 | 7.0~13.2 | 0.09 | 1200 | 42.63 | 1.21 | 0.09 | 2.18 | 18.0 | AGN12025_24J | 24 | 14.0~26.2 | 0.06 | 1200 | 42.63 | 1.21 | 0.09 | 2.18 | 18.0 | AGN12025_12L | 12 | 7.0~13.2 | 0.19 | 1900 | 73.08 | 2.07 | 0.14 | 3.53 | 28.0 | AGN12025_24L | 24 | 14.0~26.2 | 0.11 | 1900 | 73.08 | 2.07 | 0.14 | 3.53 | 28.0 | AGN12025_12M | 12 | 7.0~13.2 | 0.21 | 2200 | 82.11 | 2.33 | 0.18 | 4.67 | 30.0 | AGN12025_24M | 24 | 14.0~26.2 | 0.19 | 2200 | 82.11 | 2.33 | 0.18 | 4.67 | 30.0 | AGN12025_12H | 12 | 7.0~13.2 | 0.29 | 2500 | 89.78 | 2.54 | 0.20 | 5.19 | 35.0 | AGN12025_24H | 24 | 14.0~26.2 | 0.21 | 2500 | 89.78 | 2.54 | 0.20 | 5.19 | 35.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
