‧AC‧JGN28099

280x280x99mm
1177 CFM
CROWN ELECTRONICS AC AXIAL IMPELLER FAN 28099

Rated  Volt

Freq.

Input
  Power

Ref.
  Speed

Max.Airflow

Max.Static  Pressure

Noise

   Level

Model No

VAC

Hz

W

RPM

CFM

m3/min

Inch/H2O

mm-H2O

db(A)

JGN28099B2H

230

50/60

100/120

1400/1600

1007/1177

28.5/33

1.38/1.57

35/40

62/66

JGN28099B3H

380

50/60

100/120

1400/1600

1007/1177

28.5/33

1.38/1.57

35/40

62/66













































































































































  • ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing

  • 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request.

  • Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request.

  • CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance  +-10%




馬達類別:Capacitor Pole AC Motor

IP 防護:IP43

外框(Frame):Aluminum

葉輪(Impeller):Metal SPCC

軸承(Bearing):Ball Bearing

重量(weight):2.7 KG
