| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE08020_12J | 12 | 7.0~13.2 | 0.13 | 2400 | 27.39 | 0.78 | 0.09 | 2.23 | 25.0 | AGE08020_24J | 24 | 14.0~26.2 | 0.07 | 2400 | 27.39 | 0.78 | 0.09 | 2.23 | 25.0 | AGE08020_12L | 12 | 7.0~13.2 | 0.16 | 2700 | 31.24 | 0.88 | 0.11 | 2.82 | 29.0 | AGE08020_24L | 24 | 14.0~26.2 | 0.09 | 2700 | 31.24 | 0.88 | 0.11 | 2.82 | 29.0 | AGE08020_12M | 12 | 7.0~13.2 | 0.18 | 3100 | 36.88 | 1.04 | 0.15 | 3.74 | 34.0 | AGE08020_24M | 24 | 14.0~26.2 | 0.12 | 3100 | 36.88 | 1.04 | 0.15 | 3.74 | 34.0 | AGE08020_12H | 12 | 7.0~13.2 | 0.24 | 3400 | 40.45 | 1.15 | 0.18 | 4.50 | 36.0 | AGE08020_24H | 24 | 14.0~26.2 | 0.07 | 3400 | 40.45 | 1.15 | 0.18 | 4.50 | 36.0 | AGE08020_12U | 12 | 7.0~13.2 | 0.30 | 4300 | 51.16 | 1.45 | 0.28 | 7.20 | 43.0 | AGE08020_24U | 24 | 14.0~26.2 | 0.13 | 4300 | 51.16 | 1.45 | 0.28 | 7.20 | 43.0 |
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
