| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGC08025_12J | 12 | 7.0~13.2 | 0.14 | 2700 | 34.60 | 0.98 | 0.14 | 3.50 | 28.0 | AGC08025_24J | 24 | 14.0~26.2 | 0.08 | 2700 | 34.60 | 0.98 | 0.14 | 3.50 | 28.0 | AGC08025_48J | 48 | 28.0~56.0 | 0.05 | 2700 | 34.60 | 0.98 | 0.14 | 3.50 | 28.0 | AGC08025_12L | 12 | 7.0~13.2 | 0.12 | 3000 | 38.50 | 1.09 | 0.17 | 4.40 | 31.0 | AGC08025_24L | 24 | 14.0~26.2 | 0.10 | 3000 | 38.50 | 1.09 | 0.17 | 4.40 | 31.0 | AGC08025_48L | 48 | 28.0~56.0 | 0.07 | 3000 | 38.50 | 1.09 | 0.17 | 4.40 | 31.0 | AGC08025_12M | 12 | 7.0~13.2 | 0.15 | 3600 | 54.30 | 1.54 | 0.28 | 7.00 | 36.0 | AGC08025_24M | 24 | 14.0~26.2 | 0.16 | 3600 | 54.30 | 1.54 | 0.28 | 7.00 | 36.0 | AGC08025_48M | 48 | 28.0~56.0 | 0.07 | 3600 | 54.30 | 1.54 | 0.28 | 7.00 | 36.0 | AGC08025_12H | 12 | 7.0~13.2 | 0.26 | 4300 | 61.20 | 1.73 | 0.32 | 8.20 | 40.0 | AGC08025_24H | 24 | 14.0~26.2 | 0.23 | 4300 | 61.20 | 1.73 | 0.32 | 8.20 | 40.0 | AGC08025_48H | 48 | 28.0~56.0 | 0.14 | 4300 | 61.20 | 1.73 | 0.32 | 8.20 | 40.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
