| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE08032_12J | 12 | 7.0~13.2 | 0.15 | 3000 | 38.20 | 1.08 | 0.20 | 5.02 | 30.6 | AGE08032_12L | 12 | 7.0~13.2 | 0.30 | 4000 | 49.70 | 1.41 | 0.35 | 8.82 | 39.2 | AGE08032_12M | 12 | 7.0~13.2 | 0.26 | 4800 | 60.40 | 1.71 | 0.45 | 11.38 | 44.9 | AGE08032_24M | 24 | 14.0~26.2 | 0.14 | 4800 | 60.40 | 1.71 | 0.45 | 11.38 | 44.9 | AGE08032_12H | 12 | 7.0~13.2 | 0.46 | 5500 | 69.10 | 1.96 | 0.61 | 15.53 | 48.4 | AGE08032_24H | 24 | 14.0~26.2 | 0.23 | 5500 | 69.10 | 1.96 | 0.61 | 15.53 | 48.4 | AGE08032_48H | 48 | 14.0~26.2 | 0.14 | 5500 | 69.10 | 1.96 | 0.61 | 15.53 | 48.4 | AGE08032_12U | 12 | 7.0~13.2 | 0.68 | 6800 | 86.67 | 2.45 | 0.89 | 22.57 | 53.9 | AGE08032_24U | 24 | 14.0~26.2 | 0.29 | 6800 | 86.67 | 2.45 | 0.89 | 22.57 | 53.9 | AGE08032_48U | 48 | 14.0~26.2 | 0.21 | 6800 | 86.67 | 2.45 | 0.89 | 22.57 | 53.9 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
