| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | ASB12038B24X | 24 | 14.0~26.4 | 3.40 | 8000 | 200.00 | 5.66 | 2.26 | 57.50 | 68.0 | ASB12038B48X | 48 | 28.0~56.0 | 1.50 | 8000 | 200.00 | 5.66 | 2.26 | 57.50 | 68.0 | ASB12038B48P | 48 | 28.0~56.0 | 1.90 | 10000 | 250.00 | 7.08 | 3.54 | 89.90 | 72.0 | ASB12038B24P | 24 | 14.0~26.4 | 3.80 | 10000 | 250.00 | 7.08 | 3.54 | 89.90 | 72.0 | ASB12038B24T | 24 | 14.0~26.4 | 4.20 | 12000 | 300.00 | 8.49 | 5.10 | 129.50 | 76.0 | ASB12038B48T | 48 | 28.0~56.0 | 2.40 | 12000 | 300.00 | 8.49 | 5.10 | 129.50 | 76.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
