| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE15051_24J | 24 | 14.0~26.4 | 0.75 | 3500 | 263.00 | 7.45 | 0.82 | 20.85 | 57.0 | AGE15051_48J | 48 | 28.0~56.0 | 0.50 | 3500 | 263.00 | 7.45 | 0.82 | 20.85 | 57.0 | AGE15051_24L | 24 | 14.0~26.4 | 1.00 | 4000 | 291.00 | 8.24 | 0.91 | 23.22 | 61.5 | AGE15051_48L | 48 | 28.0~56.0 | 0.55 | 4000 | 291.00 | 8.24 | 0.91 | 23.22 | 61.5 | AGE15051_24M | 24 | 14.0~26.4 | 1.50 | 4400 | 323.00 | 9.15 | 1.06 | 26.93 | 63.5 | AGE15051_48M | 48 | 28.0~56.0 | 0.80 | 4400 | 323.00 | 9.15 | 1.06 | 26.93 | 63.5 | AGE15051_24H | 24 | 14.0~26.4 | 1.60 | 4800 | 350.00 | 9.91 | 1.24 | 31.42 | 65.5 | AGE15051_48H | 48 | 28.0~56.0 | 0.90 | 4800 | 350.00 | 9.91 | 1.24 | 31.42 | 65.5 | AGE15051_24U | 24 | 14.0~26.4 | 2.40 | 5200 | 378.00 | 10.70 | 1.36 | 34.44 | 68.0 | AGE15051_48U | 48 | 28.0~56.0 | 1.30 | 5200 | 378.00 | 10.70 | 1.36 | 34.44 | 68.0 | AGE15051_24V | 24 | 14.0~26.4 | 4.80 | 5800 | 421.62 | 11.94 | 1.69 | 42.85 | 67.4 | AGE15051_48V | 48 | 28.0~65.0 | 2.30 | 6500 | 472.50 | 13.38 | 2.12 | 53.83 | 73.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
