| 額定電壓 | 頻率 | 輸入功率 | 參考轉速 | 最大風量 | 最大風壓 | 噪音 | Model No | VAC | Range(V) | Current | RPM | CFM | m3/min | Inch/H2O | mm-H2O | db(A) | AGE25489_24L | 24 | 14.0~26.2 | 0.75 | 1400 | 506.00 | 14.33 | 0.42 | 10.59 | 52.2 | AGE25489_12M | 12 | 7.0~13.2 | 2.20 | 1700 | 595.00 | 16.85 | 0.49 | 12.45 | 59.1 | AGE25489_24M | 24 | 14.0~26.2 | 1.20 | 1700 | 595.00 | 16.85 | 0.49 | 12.45 | 59.1 | AGE25489_24L | 24 | 14.0~26.2 | 0.75 | 1400 | 506.00 | 14.33 | 0.42 | 10.59 | 52.2 | AGE25489_12M | 12 | 7.0~13.2 | 2.20 | 1700 | 595.00 | 16.85 | 0.49 | 12.45 | 59.1 | AGE25489_24M | 24 | 14.0~26.2 | 1.20 | 1700 | 595.00 | 16.85 | 0.49 | 12.45 | 59.1 | AGE25489_48M | 48 | 28.0~56.0 | 0.57 | 1700 | 595.00 | 16.85 | 0.49 | 12.45 | 59.1 | AGE25489_24H | 24 | 14.0~26.2 | 1.90 | 2000 | 684.00 | 19.37 | 0.56 | 14.32 | 63.3 | AGE25489_48H | 48 | 28.0~56.0 | 0.94 | 2000 | 684.00 | 19.37 | 0.56 | 14.32 | 63.3 | AGE25489_48U | 48 | 28.0~56.0 | 1.50 | 2300 | 747.00 | 21.15 | 0.63 | 15.97 | 71.2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request. Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request. CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
|
|
