‧DC‧BGN12025

120x120x25mm
65.1 CFM
CROWN ELECTRONICS DC IMPELLER FAN 12025

額定電壓

頻率

輸入功率

參考轉速

             最大風量

             最大風壓

噪音

Model     No

VAC

Range(V)

Current

RPM

CFM

m3/min

Inch/H2O

mm-H2O

db(A)

BGN12025B12H

12

7.0~13.2

1.0

3500

65.11

1.84

0.76

19.28

54.7

BGN12025B12H

12

7.0~13.2

0.48

3500

65.11

1.84

0.76

19.28

54.7

BGN12025B12H

12

7.0~13.2

0.23

3500

65.11

1.84

0.76

19.28

54.7



































































































































  • ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing

  • 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request.

  • Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request.

  • CROWN reserves the right to change data and improve electrical or mechanical design without notice, data tolerance  +-10%




馬達類別:DC Brushless Dc Motor

IP 防護:

外框(Frame):Plastic(94V-0)

葉輪(Impeller):Plastic(94V-0)

軸承(Bearing):Ball Bearing

重量(weight):0.18 KG
